Home > Block ice machine > Block ice machine FIB-250S - Focusun Ice Machine
Model:FIB-250S

Subject Unit Technical parameter
Power supply Voltage/Phase/Frequency 380V/3P/50Hz
Refrigerant   R22 or R404A
Capacity Kg/day 25000
Temperature Ambient temperature 35
Waterinlet temperature 20
Operating power Total running power Kw 98.8
Installment power Kw 120
Operating power of cold water pump Kw 7.5
Compressor Manufacturer   Bitzer
Refrigeration capacity Kw 199.2
Operating power Kw 83.6
Compressor COP/EER Kw/kw 2.38
Horse power Hp 30×4
Condenser power Kw 9.7
Cooling way   Water cooling
Working time Ice making time h 7.5
Ice doffing time h 0.5
Dimension Weight of each block Kg/block 50
Size of block ice (L×W×H)(mm) 480×160×700
Size of cooling tower (L×W×H)(mm) Ф3050×2780mm
Size of water feeding pipe   1-1/4"
Operating weight of cooling tower Kg 1630
Water supply pressure requirement Bar 1
