ITEM |
UNIT |
TECHNICAL PARAMETER |
|
|---|---|---|---|
Input power |
voltage/phase/HZ |
380V/3P/50Hz |
|
Refrigerant |
|
R22 or R404A |
|
Ice field |
Kg/day |
3000 |
|
Temperature |
Ambient temperature |
℃ |
35 |
Water Inlet temperature |
℃ |
20 |
|
Running power |
Total running power |
kw |
11.52 |
Total installed power |
kw |
14 |
|
Cooling water pump running power |
kw |
0.35 |
|
Compressor |
Manufacture |
|
Bitzer |
Refrigerating capacity |
kw |
21.4 |
|
Running power |
kw |
9.52 |
|
Compressor COP/EER |
Kw/kw |
2.25 |
|
Horsepower |
Hp |
20 |
|
Condenser |
Fan power |
kw |
1.65 |
Cooling way |
|
Air cooling |
|
Working time |
Ice making time |
hour（h） |
7.5 |
Ice doffing time |
hour（h） |
0.5 |
|
Outline size |
Block ice specifications |
Kg/block |
25 |
Block ice outline size |
(length×width×height)(mm) |
315×125×700 |
|
Block ice machine outline size |
(length×width×height)(mm) |
3600×1400×2200 |
|
Dimensions of water supply pipe cooling tower |
|
3/4part（3/4"） |
|
Block ice machine running weight |
kg |
2180 |
|
Water pressure requirements |
Bar |
1 |
|
